Siemens HiPath 3000 - Figure 3-67 EPSU2 - Indicators and Ports

Boards for HiPath 3000
P31003-H3550-S403-4-7620, 02/05
3-152 HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
boards.fm
Peripheral Boards
Figure 3-67 EPSU2 - Indicators and Ports
Housing cover
AC port for 100 – 240 Vac
DC port for UPSC-D
Note polarity.
Mounting
screws
LED 1
LED 2
Battery fuse
