HiPath Cordless Office
P31003-H3550-S403-4-7620, 02/05
11-4 HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
cordless.fm
Technical Data for Base Stations
11.4 Technical Data for Base Stations
BS3/1 base station
Table 11-2 Technical Data for Various Base Stations
Parameter BS3/1 and
BS3/S
BS3/3 BS4 Outdoor cover
Power supply voltage
range
42 to 54 V 42 to 54 V 42 to 54 V –
Power consumption max. 1.7 W max. 3.2 W max. 3.0 W –
Housing dimensions
(W x D x H in mm)
181 x 139 x 69 202 x 172 x 43 200 x 176 x 49 296 x 256 x 90
Weight approx. 0.3 kg approx. 0.5 kg approx. 0.5 kg approx. 1.0 kg
Temperature range for indoor use:
- 5 to + 50
o
C
for outdoor use:
- 20 to + 45
o
C
Relative humidity – – – up to 95%
Figure 11-1 BS3/1 S30807-H5482-X Base Station
