HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual

4-13

Installing HiPath 3000

Installing HiPath 3800

4.2.3.3.4 Setting Up a Two-Cabinet System Side by Side

Procedure

Caution

To guarantee sufficient ventilation in the system cabinets, allow a minimum clear-

ance of 50 mm between the base of the cabinets and the ground.

Step Activity

1. Place the system cabinet in the installation site and make sure that it is level and

stable.

2. Check that the space between the base of the basic cabinet and the ground is at

least 50 mm.

3. If necessary, set up the basic cabinet in the following way:

● Unscrew lock nut (Figure 4-1, A) on one of the cabinet feet using an open-end

wrench (wrench size = 13 mm).

● Adjust the height of the cabinet foot by turning the screw nut (Figure 4-1, B)

so that the cabinet is steady and the minimum clearance is observed.

● Fix the cabinet foot in position by tightening the lock nut (Figure 4-1, A).

4. Place the expansion cabinet beside the basic cabinet.

Note: The cabinets can be placed directly beside one another.

5. Check that the space between the base of the expansion cabinet and the ground

is at least 50 mm.

6. If necessary, set up the expansion cabinet as described in Step 3 ensuring that

both cabinets are at exactly the same level.
