Siemens HiPath 3000 Service Manual

boards.fm
P31003-H3550-S403-4-7620, 02/05
HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
3-341
Boards for HiPath 3000
Options
3.4.11 OPAL and OPALR
Introduction
The adapter cable for connecting the central board to the first optional board comes in two ver-
sions:
● OPAL (Options Adapter Cable Long) C39195-A7001-B130 (Figure 3-150 - for use in Hi-
Path 3550 and HiPath 3350 (wall housing).
● OPALR (Options Adapter Cable Long Rack) C39195-A7001-B142 (Figure 3-151) - for use
in HiPath 3500 and HiPath 3300 (19-inch housing).
OPAL interfaces
Figure 3-150 OPAL (C39195-A7001-B130)
CBCC/CBCP interface
Option board connection
Ribbon cable
folded and secured
