Installing HiPath 3000
P31003-H3550-S403-4-7620, 02/05
4-102 HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
inst_h3.fm
Installing HiPath 3750, HiPath 3700
4.3.3.4.8 Setting Up a Stacked Three-Cabinet System
Procedure
7
Caution
Up to two cabinets can be stacked.
Step Activity
1. Remove the front and rear cabinet covers.
2. Mount one stabilizer foot on the basic cabinet and one on the expansion cabinet
(EC2). Place EC2 next to the BC in the installation site and make sure that it is
level and stable. Correct any differences in height.
3. Place expansion cabinet (EC1) on basic cabinet. Insert the feet on EC1 into the
depressions on the top of the BC.
4. Attach the three cabinets using four connecting plates, each held by two screws
with washers (Figure 4-56).
Make sure that the connecting plates are mounted in the correct direction (inside
the cabinets and pointing inward).
7
DANGER
The connecting plates must be installed to ensure proper grounding for free-stand-
ing systems.
>
For U.S. only: You can install seismic anchors for greater stability, as is required in
some installations. Additional information can be found in Section 4.3.3.4.9.
Take note that the bolts and inserts included in the seismic anchor kit are designed
for concrete floors. Bolts for other surfaces must be requested or supplied separate-
ly.
