Siemens HiPath 3000 Service Manual

start_h3.fm
P31003-H3550-S403-4-7620, 02/05
HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
5-3
Starting Up HiPath 3000
Starting Up HiPath 3800
5.2.2 Supplying the System with Power
Procedure
RUN LEDHiPath 3800
The CBSAP features a RUN LED that signals the system boot status in three phases:
● Phase 1: Basic tasks (recovery, database, query) are started.
● Phase 2: Loadware is installed for peripheral boards.
● Phase 3: Data is installed for peripheral boards.
The RUN LED flashes at a different rhythm to indicate each specific phase. The phases are
always separated by a 3-second pause during which the LED is not lit.
Step Activity
1. Plug in the power supply cable for the system cabinet(s).
2. Position all LUNA2 power supply switches to “DC-ON”.
Note: Startup does not begin until the switches on all LUNA2 units are in “DC-ON”
position.
3. Monitor the RUN LED of the CBSAP. The individual steps of the system boot
(Table 5-2) can be observed this way.
Table 5-2 RUN LED - LED Status Meaning
RUN LED Meaning
1st flash-
ing
rhythm
2nd flash-
ing
rhythm
3rd flash-
ing
rhythm
short short long Phase 1: Basic tasks (recovery, database, query) are
started.
short long short Phase 2: Loadware is installed for peripheral boards.
short long long Phase 3: Data is installed for peripheral boards.
Definition of the flashing rhythms:
● short = 0.25 s on/0.25 s off
● long = 0.75 s on/0.25 s off
>
The HiPath 3800 is ready when the date “1. JAN 00” and the time “00:00” appear in
the display on the system telephone.
