Installing HiPath 3000
Installing HiPath 3750, HiPath 3700
Static traffic capacity
The static traffic capacity of the HiPath 3750 and HiPath 3700 systems can be determined as
follows.
Table 4-17 HiPath 3750 and HiPath 3700 - Static Traffic Capacity
HiPath 3750
HiPath 3700
Slots per PCM seg-
ment
Static traffic capac-
ity per PCM seg-
ment
Total static traffic
capacity of the
system
Single-cabinet sys-
tem
(see Figure 4-89)
02 + 03 64 erlangs
192 erlangs04 + 05 64 erlangs
06 + 07 + 08 64 erlangs
Two-cabinet system
(see Figure 4-90)
02 + 03 64 erlangs
448 erlangs
04 + 05 64 erlangs
06 + 07 + 08 64 erlangs
10 + 11 64 erlangs
12 + 13 64 erlangs
14 + 15 64 erlangs
16 + 17 64 erlangs
Three-cabinet sys-
tem
(see Figure 4-91)
02 + 03 64 erlangs
448 erlangs
04 + 05 64 erlangs
06 + 07 + 08 64 erlangs
10 + 11 + 19 + 20 64 erlangs
12 + 13 + 21 + 22 64 erlangs
14 + 15 + 23 + 24 64 erlangs
16 + 17 + 25 + 26 64 erlangs
