Installing HiPath 3000
P31003-H3550-S403-4-7620, 02/05
4-190 HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
inst_h3.fm
Installing HiPath 3550, HiPath 3350, HiPath 3500, and HiPath 3300
4.4.4.5 Installing a HiPath 3500 or HiPath 3300 in a Cabinet
Procedure for 19-inch cabinets (Figure 4-108)
Step Activity
1. HiPath 3500 only: Attach the two angle brackets (A) to the 19-inch cabinet using
two screws per bracket.
2. Attach the two angle brackets (B) to the left and right of the HiPath 3500 or HiPath
3300 using two screws per bracket.
3. Slide the HiPath 3500 or HiPath 3300 system into the 19-inch cabinet and attach
it to the left and right of the 19-inch frame with screws.
