ISDN Terminals for HiPath 3000
10.11 ISDN Terminals for HiPath 3000
An S
0
bus in the HiPath 3000 system family can support up to eight ISDN terminals. Each ter-
minal can be dialed selectively under its multiple subscriber number or station number.
The features that can be activated depend on the type of S
0
terminal used. Different ISDN fea-
tures are supported depending on the terminal used. Analog station users can activate system
features by means of code procedures. The telephones support only those system features
which can be activated in the idle state.
The dialing behavior of ISDN terminals corresponds to that of DP terminals. The substitute
codes “75” and “76” can be used for the characters “*” and “#” which cannot be used in the ISDN
protocol.
Boards for connecting ISDN terminals
Refer to Section 9.2.2 for information on upgrading peripheral boards for HiPath 3750 and Hi-
Path 3700.
Connecting with an optiPoint ISDN adapter
System HiPath 3800 HiPath 3750
HiPath 3700
HiPath 3550
HiPath 3500
HiPath 3350
HiPath 3300
Hardware requirements Free S
0
port on
STMD3
Free S
0
port on
STMD8
Free S
0
port on
CBCC
CBRC
STLS2/4
STLS4R
STLSX2/4
STLSX4R
Free S
0
port on
CBCC
CBRC
STLS2/4
STLS4R
STLSX2/4
STLSX4R
>
It is also possible to connect an ISDN device to an existing optiPoint 500 telephone
using an optiPoint ISDN Adapter (except for optiPoint 500 entry and optiPoint 500
economy).
