Boards for HiPath 3000
P31003-H3550-S403-4-7620, 02/05
3-18 HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
boards.fm
Central Boards
3.2 Central Boards
3.2.1 CBCC
Introduction
The CBCC board (Central Board with Coldfire Com, S30810-Q2935-A301) performs all central
control and switching functions for HiPath 3550 and HiPath 3350 (see Figure 3-1).
Subboards
The following subboards can be used depending on the application:
● Clock module CMA or CMS (optional)
● MMC multimedia card
● IMODN integrated modem card new (optional)
● LIM LAN interface module (optional)
● MPPI music on hold (optional)
● EVM entry voice mail (optional)
Outputs, interfaces
● Eight digital U
P0/E
subscriber lines
For example, U
P0/E
workpoint clients or BS3/1 base stations for HiPath Cordless Office can
be connected here.
● Four analog T/R subscriber lines
For U.S. only: These interfaces do not support the connection of external extensions via
OPS (Off-Premises Station) signaling.
7
Caution
The system must be powered down and de-energized before removing or inserting
all boards in the HiPath 3550, HiPath 3350, HiPath 3500, HiPath 3300 and before
removing or inserting the central boards of the HiPath 3800, HiPath 3750 and Hi-
Path 3700.
>
The CBCC central control board must be upgraded for HiPath 3000 V5.0. The “old”
CBCC board S30810-Q2935-A201 is not supported.
For Deutsche Telekom AG only: The CBCP board S30810-Q2935-B201 is not sup-
ported by HiPath 3000 V5.0 and must be replaced by a CBCC board S30810-
Q2935-A301.
