boards.fm
P31003-H3550-S403-4-7620, 02/05
HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
3-17
Boards for HiPath 3000
Overview
HiPath 3300
Note: The HiPath 3550, HiPath 3350, HiPath 3500 and HiPath 3300 peripheral boards must
be firmly inserted into their slots; otherwise contact problems can cause board failure.
ANI4R S30807-Q6917-Z103 Option (for selected countries only)
CBRC S30810-Q2935-Z301 Central board
CMA S30807-Q6931-X Central board
CMS S30807-Q6928-X Central board
CUPR S30777-Q751-Z Central board
EVM S30807-Q6945-X Option
EXMR S30122-K7403-Z Option
HXGR3 S30810-K2943-Z Peripheral board
IMODN S30807-Q6932-X100 Central board
IVMP8R S30122-K7379-Z100 Peripheral board (not for U.S.)
IVMS8R S30122-K7379-Z Peripheral board
LIM S30807-Q6930-X Central board
MMC S30122-X8002-X10 Central board
MPPI S30122-K7275-B Option
OPALR C39195-A7001-B142 Cable
PDM1 S30807-Q5692-X100 Option
SLU8R S30817-K922-Z301 Peripheral board
STLS4R S30817-K924-Z313 Peripheral board
STLSX4R S30810-K2944-Z Peripheral board
STRBR S30817-Q932-Z Option
TLA4R S30817-Q923-Zxxx Peripheral board (not for U.S.)
TMGL4R S30810-K2918-Z Peripheral board (for U.S. only)
UAMR S30122-X7402-Z Option (not for U.S.)
UPSC-DR S30122-K7373-M900 Central board
8SLAR S30810-K2925-Z Peripheral board
Table 3-2 HiPath 3000 - Overview of All Boards Models Used
Board Part number Function
