inst_h3.fm
P31003-H3550-S403-4-7620, 02/05
HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
4-51
Installing HiPath 3000
Installing HiPath 3800
Figure 4-29 HiPath 3800 - Connectors and Jacks on the Backplane of the Basic Cabinet
X101
X102
X103
X104
X105
X109
X110
X111
X112
X201
X116
X209
X212
X211
