Siemens HiPath 3000 Service Manual

boards.fm
P31003-H3550-S403-4-7620, 02/05
HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
3-363
Boards for HiPath 3000
Options
3.4.18 V.24 Adapter
The V.24 adapter is required as an adapter between the 25-pin connector on the cable
(C39195-Z7267-C13) and a 9-pin jack for connection to the V.24 interface on all HiPath 3000
V1.2 (or later) systems.
V.24 adapter assignment
Table 3-169 V.24 Adapter Assignment (C39334-Z7080-C2)
9-pin jack Signal 25-pin jack
Pin Pin
1 DCD 8
2 RxD 3
3 TxD 2
4DTR20
5GND7
6DSR6
7RTS4
8CTS5
9RI22
