Siemens HiPath 3000 Service Manual

inst_h3.fm
P31003-H3550-S403-4-7620, 02/05
HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
4-47
Installing HiPath 3000
Installing HiPath 3800
Time-division multiplex channels for peripheral boards
The following table lists the number of time-division multiplex channels that the different boards
require.
Table 4-4 Maximum Number of Time-Division Multiplex Channels Required Per Board
Board Maximum number of time-division multiplex channels re-
quired
DIU2U 60
DIUN2 60
IVMN8 8
IVMNL 24
SLCN 64
1
1 A time-division multiplex channel is required if a call is being conducted over the “home SLCN board” of a mobile tele-
phone. If a call is being conducted over a “Current location SLCN board”, additional time-division multiplex channels will
be required. More information is provided in Section 11.6, “Multi-SLC and System-Wide Networking”.
SLMA 24
2
2 The current number of time-division multiplex channels required is determined by the number of active stations.
SLMA8 8
2
SLMO2 48
2 3
3 The maximum number of masters and slaves possible is taken into consideration.
SLMO8 16
2 3
STMD3 16
STMI2 32
STMI2 + PDMX
4
4 PDMX is not currently released.
64
TM2LP 8
TMC16 16
TMDID 8
TMEW2 4
