HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
6-59
HiPath 5000 Startup and Administration
Connecting an Uninterruptible Power Supply to HiPath 5000
6.13 Connecting an Uninterruptible Power Supply to HiPath 5000
Online’s P 500 uninterruptible power supply (UPS) was certified for use with HiPath 5000.
The P 500 UPS is fed through the AC power cord to the HiPath 5000 server. The device bridges
power failures lasting 5 - 10 minutes by means of an integrated battery.
P 500 UPS - Front and Rear Panel
7
Caution
For safety reasons and for protection against guarantee claims, changes to the UPS
settings may only be performed by specially trained technicians.
The manufacturer’s safety and operating instructions must be observed.
Figure 6-4 P 500 UPS - Front and Rear Panel
21 3 4 5 6
8
7
