Boards for HiPath 3000
P31003-H3550-S403-4-7620, 02/05
3-212 HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
boards.fm
Peripheral Boards
LED statuses and their meanings
● H300 LED (see Figure 3-85): Reference clock display (clock is generated if this feature was
configured using HiPath 3000 Manager E).
– On: Reference clock for clock generator is created.
– Off: No reference clock
● LEDs H301 to H308 (see Figure 3-85)
Table 3-96 STMD8 - LED Statuses (H301 to H308)
LED Status
(on/off)
Meaning Action
During Startup and Initialization
Flickering
(50/50 ms)
Board test unsuccessful Replace board.
Flashing
(100/100 ms)
Board not configured Inspect visually, remove and re-insert
board if necessary.
Replace board if flashing continues.
On Loading in progress
Flashing
(100/100 ms)
Code could not be loaded Replace board.
Off Board loaded
Flashing
(500/500 ms)
Board loaded but not yet activated
During Operation
On ISDN layer 2 activated
Flickering
(450/50 ms)
Dependability test (loopback test)
in progress
Flashing
(500/500 ms)
Board is out of service (e.g. S300/x
“closed”)
Check whether board was deactivat-
ed using HiPath 3000 Manager E or
lockout switch.
Off ISDN layer 2 not activated
