boards.fm
P31003-H3550-S403-4-7620, 02/05
HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
3-307
Boards for HiPath 3000
Peripheral Boards
3.3.42 TS2 (Not for U.S.), TS2R (Not for U.S.)
Introduction
The board contains a four-wire interface with S
2M
code for connection to the public telecommu-
nications network or private networks.
Up to thirty trunk calls can be conducted simultaneously via the S
2M
interface. The total trans-
mission speed including signaling and synchronization is 2048 Mbps.
Two trace files are available:
● Implemented up to and including V4.0:
–TS2 (Trunk Module S2M) S30810-Q2913-X100 (Figure 3-128) - for use in HiPath 3550
(wall housing)
–TS2R (Trunk Module S2M Rack) S30810-K2913-Z100 (Figure 3-129) - for use in Hi-
Path 3500 (19-inch housing)
● Implemented in V5.0 and later:
–TS2 (Trunk Module S2M) S30810-Q2913-X300 (Figure 3-128) - for use in HiPath 3550
(wall housing)
–TS2R (Trunk Module S2M Rack) S30810-K2913-Z300 (Figure 3-129) - for use in Hi-
Path 3500 (19-inch housing)
Board usage is subject to the following restrictions:
● Only one TS2/TS2R board allowed (primary multiplex access)
● For slot 7 or 9 only
To support country-specific CAS protocols, you can use the Euro-ISDN CAS gateway ECG.
The ECG cabinet is a protocol converter that converts the Euro-ISDN protocol into the Channel
Associated Signaling CAS protocol. Refer to the installation instructions, which are provided
with each ECG cabinet, for information on the connection and power supply.
For HiPath 3000 V1.0 and later, you can also use the new TMCAS board to support country-
specific CAS protocols.
>
In HiPath 3000/5000 V5.0 and later, the B channels in the TS2 and TS2R boards
are subject to license. Consequently, the two boards below have been assigned
a new hardware identification code. The new codes prevent the boards from be-
ing used in earlier versions. Functionality and layout of the boards have not been
changed.
