inst_h3.fm

P31003-H3550-S403-4-7620, 02/05

HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual

4-37

Installing HiPath 3000

Installing HiPath 3800

Figure 4-19 HiPath 3800 - Slots for LUNA2 and REALS in the Basic Cabinet (With Out-

er Panel Mounted)

Figure 4-20 HiPath 3800 - Slots for LUNA2 in the Expansion Cabinet (With Outer Panel

Mounted)

Fixing screws
