System Data
P31003-H3550-S403-4-7620, 02/05
2-32 HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
sysdat.fm
Environmental Conditions
2.9 Environmental Conditions
2.9.1 Electrical Operating Conditions
● Operating limits
Room temperature: + 5 ...+ 40 °C (41 ... 104 °F)
absolute humidity: 2 - 25 g H
2
O/m
3
Relative humidity: 5 - 80%
● System ventilation is by convection only. Automatic ventilation is required when using the
HG 1500 in HiPath 3550 and HiPath 3350.
2.9.2 Mechanical Operating Conditions
The systems are intended for stationary use.
7
Caution
Avoid exposing the system to direct sunlight and heaters (excessive heat may dam-
age the system).
Systems covered with condensation must be dried before being used. Do not start
up the system until it has thoroughly dried.
