Identifying System Power Requirements
P31003-H3550-S403-4-7620, 02/05
D-8 HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
power_calc.fm
HiPath 3350 Board Power Requirement
D.4 HiPath 3350 Board Power Requirement
Table D-7 Nominal Output of the HiPath 3350 Power Supply Units
Power Supply Unit Part Number Max. Nominal Output in W
5V –48V
PSUP S30122-K5658-M 15.0 19.2
UPSC-D S30122-K5660-M300 20.0
1
1 Nominal output = 40 W. Due to build-up of heat, not more than 20 W may be withdrawn.
53.0
UPSC-D with EPSU2 S30122-K5660-M300 with
S30122-K7221-X2
40.0 140.0
>
You must check whether the total power requirement of the boards used and the
connected workpoint clients exceeds the maximum possible output of the PSUP or
the UPSC-D with or without EPSU2. Section D.8 contains a sample calculation.
Table D-8 HiPath 3350 Board Power Requirement
Board or Component Part Number Net Power Requirement in
W
5V –48V
BS3/1 S30807-H5482-X – 2.0
BS3/3 S30807-H5485-X – 3.0
CBCC (including submod-
ules)
S30810-Q2935-A301 7.0 0.5
GEE12 S30817-Q951-Axxx 0.5 –
GEE16 S30817-Q951-Axxx 0.5 –
GEE50 S30817-Q951-Axxx 0.5 –
HXGS3 (including ventilator
kit)
S30810-Q2943-X 10.0 2.8
IVMP8 S30122-Q7379-X100 2.6 0.3
PDM1 S30807-Q5692-X100 – 5.0
SLU8 S30817-Q922-A301 0.8 –
STLS2 S30817-Q924-B313 0.6 –
STLS4 S30817-Q924-A313 1.0 –
STRB S30817-Q932-A 0.5 –
TLA2 S30817-Q923-Bxxx 0.1 –
