Identifying System Power Requirements
HiPath 3350 Board Power Requirement
TLA4 S30817-Q923-Axxx 0.2 –
TLA8 S30817-Q926-Axxx 0.4 –
TMGL4 S30810-Q2918-X 4.7
1
0.1
1
TMQ4 S30810-Q2917-X 3.8 –
V24/1 S30807-Q6916-X100 0.3 –
4SLA S30810-Q2923-X200 0.7 0.7
8SLA S30810-Q2923-X100 1.3 1.3
16SLA S30810-Q2923-X 2.5 2.5
1 Identified at a traffic flow of 0.8 Erlang
Table D-8 HiPath 3350 Board Power Requirement
Board or Component Part Number Net Power Requirement in
W
5V –48V
