Identifying System Power Requirements

HiPath 3550 Board Power Requirement

SLMO24 S30810-Q2901-X 1.5 –

SLU8 S30817-Q922-A301 0.8 –

STLS2 S30817-Q924-B313 0.6 –

STLS4 S30817-Q924-A313 1.0 –

STRB S30817-Q932-A 0.5 –

TLA2 S30817-Q923-Bxxx 0.1 –

TLA4 S30817-Q923-Axxx 0.2 –

TLA8 S30817-Q926-Axxx 0.4 –

TMAMF S30810-Q2587-A400 1.8

16.9

TMCAS S30810-Q2938-X Not Available

TMGL4 S30810-Q2918-X 4.7

0.1

TMQ4 S30810-Q2917-X 3.8 –

TST1 S30810-Q2919-X 0.8 –

TS2 S30810-Q2913-X300 0.9 –

V24/1 S30807-Q6916-X100 0.3 –

4SLA S30810-Q2923-X200 0.7 0.7

8SLA S30810-Q2923-X100 1.3 1.3

16SLA S30810-Q2923-X 2.5 2.5

1 Identified at a traffic flow of 0.8 Erlang

Table D-6 HiPath 3550 Board Power Requirement

Board or Component Part Number Net Power Requirement in

5V –48V
