boards.fm
P31003-H3550-S403-4-7620, 02/05
HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
3-331
Boards for HiPath 3000
Options
Connection of EXMR
Figure 3-143 EXMR Connection to HiPath 3500 and HiPath 3300
Front panel
of the system
Cinch jack
X1
X2
Cable C39195-Z7001-C79
EXMR
(component side)
