Central Boards
X1 and X3 contact assignments
S
0
interface assignment
Table 3-11 CBRC - X1 and X3 Contact Assignments
Contact Connector X1 Connector X3
U
P0/E
T/R
14 U
P0/E
port 1a T/R port 1a
15 U
P0/E
port 1b T/R port 1b
24 U
P0/E
port 2a T/R port 2a
25 U
P0/E
port 2b T/R port 2b
34 U
P0/E
port 3a T/R port 3a
35 U
P0/E
port 3b T/R port 3b
44 U
P0/E
port 4a T/R port 4a
45 U
P0/E
port 4b T/R port 4b
54 U
P0/E
port 5a –
55 U
P0/E
port 5b –
64 U
P0/E
port 6a –
65 U
P0/E
port 6b –
74 U
P0/E
port 7a –
75 U
P0/E
port 7b –
84 U
P0/E
port 8a –
85 U
P0/E
port 8b –
Table 3-12 CBRC - S
0
Interface Assignment (RJ45 Jacks)
X9
Pin
S
0
port 1 X9
Pin
S
0
port 2
11–21–
12–22–
13 S
0
port 1, transmit + 23 S
0
port 2, transmit +
14 S
0
port 1, receive + 24 S
0
port 2, receive +
15 S
0
port 1, receive – 25 S
0
port 2, receive –
16 S
0
port 1, transmit – 26 S
0
port 2, transmit –
17–27–
18–28–
