Siemens HiPath 3000 Service Manual

Boards for HiPath 3000
P31003-H3550-S403-4-7620, 02/05
3-118 HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
boards.fm
Peripheral Boards
RJ45 jack assignment
Flashing
(500/
500 ms)
Flashing
(500/
500 ms)
Lockout switch activated during a call
On Off Board locked or board error occurred Check whether board was deacti-
vated using HiPath 3000 Manag-
er E or lockout switch.
Table 3-48 IVMNL/IVMN8 - RJ45 Jack Assignment
Pin Signal Description
1 Tx + Transmit +
2 Tx – Transmit –
3Rx+Receive+
4 – Not used
5 – Not used
6Rx–Receive–
7 – Not used
8 – Not used
Table 3-47 IVMNL/IVMN8 - LED Statuses
LED
Red
Green
LED
Meaning Action
