Peripheral Boards
LED statuses and their meanings
Connection types
● Fiber optic cable
The fiber optic cable is only connected via the front panel. The opto-electronic converter
AMOM must be used to connect a fiber optic cable to the 15-pin Sub-D jacks on the front
panel.
● Copper cable
The copper cable is only connected via the 15-pin Sub-D jacks on the front panel.
Table 3-32 DIUN2 - LED Statuses
Red LED Green
LED
Status Action
Off Off Board not receiving power or not plugged in
correctly.
Board is out of order.
Check plug contact on
board.
On Off Board is receiving power and board test is
in progress.
Board is defective if status remains un-
changed (board test unsuccessful).
Replace board.
Loadware loading not successfully com-
pleted. Board is faulty.
Replace board.
Error detected on board.
Board is deactivated (not applicable to er-
rors detected by test loops) or board was
deactivated using HiPath 3000 Manager E.
Check whether the board
was deactivated using Hi-
Path 3000 Manager E. If
not, replace board.
Flashing Off Loadware is being loaded.
Off On Board test completed successfully. Board is
OK (idle state).
Off Flashing At least one channel is activated.
