Boards for HiPath 3000
P31003-H3550-S403-4-7620, 02/05
3-154 HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
boards.fm
Peripheral Boards
AC power 100 - 240 V AC
Frequency range 47 to 63 Hz
Connected output 200 W
Output power consumption/
nominal output
140 W
Mains/nominal voltage 54.2 V
UPS batteries V39113-W5123-E891
Four batteries are supplied
built-in.
V39113-W5123-E891
Batteries are not included in
the scope of supply and must
be ordered separately.
Battery operation:
● Permitted batteries
Manufacturer/type num-
ber
● Number of batteries
● Size (Ah)
● Nominal voltage
● Overload protection
● CSB/EVX-1270, Hitachi/HP6.5-12, Yuasa/NP6-12, Varta/
Noack 43720303, Sonnenschein/0719143200, Panasonic/
LCR12-7P
● 4 units, 12 V each
● 7Ah
● 48 V (fully charged 54 V, discharge to 44 V)
● Melting fuse 5 x 20 mm, 2.5 A/slow-blowing
Nominal current 2.5 A
Overload protection Electronic current limiting circuit
Ambient temperature In buildings, +5 to +45 °C (41 to 113 °F)
Humidity 95%, non-condensing
Cooling Natural convection
Protection IP 21 (DIN 40050)
Housing dimensions (W x D
x H in mm)
250 x 114 x 317
Weight approx. 14.1 kg (incl. batteries) approx. 4.1 kg (without batter-
ies)
Symbol CE
Personal safety, insulation EN60950 and IEC950
Grounding, shielding Protection class 1, output is floating against ground
Table 3-65 EPSU2 - Technical Specifications
EPSU2
S30122-K7221-X1
EPSU2
S30122-K7221-X2
