Siemens HiPath 3000 Service Manual

Boards for HiPath 3000
P31003-H3550-S403-4-7620, 02/05
3-180 HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
boards.fm
Peripheral Boards
17 17a 17 Ring
Port 17
Not used for
SLMO8
42 17b 17 TIP
18 18a 18 Ring
Port 18
43 18b 18 TIP
19 19a 19 Ring
Port 19
44 19b 19 TIP
20 20a 20 Ring
Port 20
45 20b 20 TIP
21 21a 21 Ring
Port 21
46 21b 21 TIP
22 22a 22 Ring
Port 22
47 22b 22 TIP
23 23a 23 Ring
Port 23
48 23b 23 TIP
24 24a 24 Ring
Port 24
49 24b 24 TIP
Table 3-79 SLMO2/SLMO8 - Connector Panel Assignment with CHAMP Jack (For U.S.
Only)
CHAMP jack SLMO2, SLMO8 Notes
