boards.fm
P31003-H3550-S403-4-7620, 02/05
HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
3-231
Boards for HiPath 3000
Peripheral Boards
DIP-FIX switch positions
Table 3-103 TIEL - Functions of the DIP-FIX Switches
Function CCT 1 CCT 2 CCT 3 CCT 4
Switch-
es
Position Switch-
es
Position Switch-
es
Position Switch-
es
Position
Type 1
(Figure 3-96)
S103
S102
1 - 2
4 - 6
1 - 2
S203
S202
1 - 2
4 - 6
1 - 2
S303
S302
1 - 2
4 - 6
1 - 2
S403
S402
1 - 2
4 - 6
1 - 2
Type 1A
(Figure 3-97)
S103
S102
1 - 3
4 - 6
1 - 2
S203
S202
1 - 3
4 - 6
1 - 2
S303
S302
1 - 3
4 - 6
1 - 2
S403
S402
1 - 3
4 - 6
1 - 2
Type 1B or 5
(Figure 3-98)
S103
S102
1 - 3
4 - 5
1 - 2
S203
S202
1 - 3
4 - 5
1 - 2
S303
S302
1 - 3
4 - 5
1 - 2
S403
S402
1 - 3
4 - 5
1 - 2
Type 2
(Figure 3-99
and
Figure 3-100)
(factory default)
S103
S102
Open
1 - 2
S203
S202
Open
1 - 2
S303
S302
Open
1 - 2
S403
S402
Open
1 - 2
Type 3 S103
S102
1 - 2
4 - 6
1 - 3
S203
S202
1 - 2
4 - 6
1 - 3
S303
S302
1 - 2
4 - 6
1 - 3
S403
S402
1 - 2
4 - 6
1 - 3
2 speech wires S104 1 - 3
4 - 6
S204 1 - 3
4 - 6
S304 1 - 3
4 - 6
S404 1 - 3
4 - 6
4 speech wires
(factory default)
S104 1 - 2
4 - 5
S204 1 - 2
4 - 5
S304 1 - 2
4 - 5
S404 1 - 2
4 - 5
