Siemens HiPath 3000 Service Manual

Boards for HiPath 3000
P31003-H3550-S403-4-7620, 02/05
3-240 HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
boards.fm
Peripheral Boards
Table 3-106 TIEL - Assignment (SU Xx8) (For U.S. Only)
#
a-Wire
(Tip)
b-Wire
(Ring)
SU connec-
tor
TIEL CHAMP jack, MDF Notes
BP: Xx8
1
wht/blu 19 1Ra
Port 1
1Ring
● Transmit with 4-wire
speech
● Transmit + receive with
2-wire speech
blu/wht 39 1Rb 26 Tip
2
wht/ora 38 1Sa 2 Ring 1
Receive with 4-wire
speech
ora/wht 48 1Sb 27 TIP 1
3
wht/grn 27 2Ra 3 E
Signal wires
grn/wht 47 2Rb 28 System ground
4
wht/brn 16 2Sa 4 M
brn/wht 46 2Sb 29 System battery
5
wht/gry 05 3Ra
Port 2
5Ring
● Transmit with 4-wire
speech
● Transmit + receive with
2-wire speech
gry/wht 45 3Rb 30 Tip
6
red/blu 14 3Sa 6 Ring 1
Receive with 4-wire
speech
blu/red 44 3Sb 31 TIP 1
7
red/ora 23 4Ra 7 E
Signal wires
ora/red 43 4Rb 32 System ground
8
red/grn 32 4Sa 8 M
grn/red 42 4Sb 33 System battery
9
red/brn 11 5Ra
Port 3
9Ring
● Transmit with 4-wire
speech
● Transmit + receive with
2-wire speech
brn/red 31 5Rb 34 Tip
10
red/gry 02 5Sa 10 Ring 1
Receive with 4-wire
speech
gry/red 22 5Sb 35 TIP 1
11
blk/blu 13 6Ra 11 E
Signal wires
blu/blk 33 6Rb 36 System ground
12
blk/ora 04 6Sa 12 M
ora/blk 24 6Sb 37 System battery
