Boards for HiPath 3000
P31003-H3550-S403-4-7620, 02/05
3-260 HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
boards.fm
Peripheral Boards
Table 3-120 TMC16 (For U.S. Only) - Connector Panel Assignment with CHAMP Jack
CHAMP jack TMC16 Notes
11a1 Ring
Port 1
26 1b 1 TIP
22a2 Ring
Port 2
27 2b 2 TIP
33a3 Ring
Port 3
28 3b 3 TIP
44a4 Ring
Port 4
29 4b 4 TIP
55a5 Ring
Port 5
30 5b 5 TIP
66a6 Ring
Port 6
31 6b 6 TIP
77a7 Ring
Port 7
32 7b 7 TIP
88a8 Ring
Port 8
33 8b 8 TIP
99a9 Ring
Port 9
34 9b 9 TIP
10 10a 10 Ring
Port 10
35 10b 10 TIP
11 11a 11 Ring
Port 11
36 11b 11 TIP
12 12a 12 Ring
Port 12
37 12b 12 TIP
13 13a 13 Ring
Port 13
38 13b 13 TIP
14 14a 14 Ring
Port 14
39 14b 14 TIP
15 15a 15 Ring
Port 15
40 15b 15 TIP
16 16a 16 Ring
Port 16
41 16b 16 TIP
