Siemens HiPath 3000 Service Manual

boards.fm
P31003-H3550-S403-4-7620, 02/05
HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
3-285
Boards for HiPath 3000
Peripheral Boards
Contact assignment
Note: Pinouts shown are at the board itself. The main distribution frame cable (MDF cable) sup-
plied reverses the signal order before the MDF.
Table 3-136 TMGL4 (For U.S. Only) - Contact Assignment
Contact Connector X2 Port
1 b-wire (ring), trunk 1 1
2 a-wire (tip), trunk 1
3 b-wire (ring), trunk 2 2
4 a-wire (tip), trunk 2
5 b-wire (ring), trunk 3 3
6 a-wire (tip), trunk 3
7 b-wire (ring), trunk 4 4
8 a-wire (tip), trunk 4
