Siemens HiPath 3000 Service Manual

Boards for HiPath 3000
P31003-H3550-S403-4-7620, 02/05
3-300 HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
boards.fm
Peripheral Boards
LED statuses and their meanings
● H1 (red) and H2 (green) LEDs
● H3 LED (see Figure 3-121): Reference clock display (clock is generated if this feature was
configured using HiPath 3000 Manager E).
– On: Reference clock for clock generator is created.
– Off: No reference clock
Table 3-146 TMS2 (Not for U.S.) - LED Statuses
Red LED Green
LED
Status Action
Off Off Board not receiving power or not
plugged in correctly.
Board is out of order.
Check plug contact on
board.
On Off Board is receiving power and board test
is in progress.
Board is defective if status remains un-
changed (board test unsuccessful).
Replace board.
Loadware loading not successfully com-
pleted. Board is faulty.
Replace board.
Error detected on board.
Board is deactivated (not applicable to
errors detected by test loops) or board
was deactivated using HiPath 3000 Man-
ager E.
Check whether the
board was deactivated
using HiPath 3000 Man-
ager E. If not, replace
board.
Flashing Off Loadware is being loaded.
Off On Board test completed successfully.
Board is OK (idle state).
Off Flashing At least one subscriber line circuit is acti-
vated.
