boards.fm
P31003-H3550-S403-4-7620, 02/05
HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
3-309
Boards for HiPath 3000
Peripheral Boards
Network interfaces
The TS2 board is connected to the network transfer point (NT1) via the symmetrical line (120
ohms, four-wire twisted-pair cable) at X2 or via an MW line at X5.
Note: use the connection kits listed on Page 3-311 for NT connections in Spain and Portugal.
● Symmetrical line (120 ohms)
The maximum cable length (approx. 130 m) depends on the quality of the cable used and
its signal attenuation. Use shielded cables only to guarantee proper operation.
Connect the cable to the X2 using an 8-pin Wieland terminal (TS2 only).
● MW line (MW8 jack (RJ48C))
The shielded 8-pin MW8 (RJ48C) jack X5 is provided for connecting MW lines. The maxi-
mum cable length (approx. 100 m) depends on the quality of the cable used and its signal
attenuation.
Table 3-148 Contact Assignments for X2 Connector
Contact X2 (TS2 only)
1 –48 V (NT1 feeding), max. 15 W
2 0 V (NT1 feeding)
3GND
4 Board ID for TMCAS
5 a-wire (T), transmit
6 b-wire (R), transmit
7 a-wire (T), receive
8 b-wire (R), receive
Table 3-149 Contact Assignments for the MW8 (RJ48C) jack X5
Pin X5 Pin X5
1 b-wire (R), receive 6 Free
2 a-wire (T), receive 7 Free
3Free8Free
4 b-wire (R), transmit 11 GND
5 a-wire (T), transmit 12 GND
An additional line must be provided from pins 1 and 2 on the X2 connector to NT1 for NT1
feeding.
