boards.fm
P31003-H3550-S403-4-7620, 02/05
HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
3-319
Boards for HiPath 3000
Options
13 – – TA3 to SLA* a
14 – – TB3 to SLA* b
15 – – TA4 to SLA* a
16 – – TB4 to SLA* b
* = or to free analog port
Table 3-154 ALUM4 - Interface Assignments (For U.S. Only)
Pin X3
(to MDF)
X4
(to MDF)
Y-Cable from X6 to
TMGL4
Y-Cable from X6 to Ana-
log Ports
1
1 To the analog station ports on the CBCC (recommended) or to four consecutive ports on an 8SLA board.
Pin Assignment Pin Assignment
1 R from trunk
1
R to station 1 1 T to TMGL4 port 1 9 T to analog port 1
2 T from trunk
1
T to station 1 2 R to TMGL4 port 1 10 R to analog port 1
3 R from trunk
2
R to station 2 3 T to TMGL4 port 2 11 T to analog port 2
4 T from trunk
2
T to station 2 4 R to TMGL4 port 2 12 R to analog port 2
5 R from trunk
3
R to station 3 5 T to TMGL4 port 3 13 T to analog port 3
6 T from trunk
3
T to station 3 6 R to TMGL4 port 3 14 R to analog port 3
7 R from trunk
4
R to station 4 7 T to TMGL4 port 4 15 T to analog port 4
8 T from trunk
4
T to station 4 8 R to TMGL4 port 4 16 R to analog port 4
Note: Pinouts shown are at the board itself. The supplied main distribution frame cable (MDF
cable) reverses the signal order for X3 and X4 before the MDF.
Table 3-153 ALUM4 - Interface Assignments (Not for U.S.)
Contact Connector X3 Connector X4 Connector X6
