Siemens HiPath 3000 Service Manual

Boards for HiPath 3000
P31003-H3550-S403-4-7620, 02/05
3-322 HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
boards.fm
Options
Connector assignment
Table 3-155 AMOM - 15-Pin Sub-D Plug Assignment
Pin Signal Signal description Route
4 LWLO0_FRONT Data output on the optical fiber in-
terface
Input
5 GND Ground return path for the +5-
Vpower supply
Input/output
6 SCAN_IN0 Adapter test Output
7 SCAN_IN0 Adapter test Output
10 +5 V +5-V power supply Input
11 LWLI0_FRONT Data input on the optical fiber inter-
face (front)
Output
12 GND Ground return path for the +5-
Vpower supply
Input/output
14 +5 V +5-V power supply Input
No other pins used.
