Siemens HiPath 3000 Service Manual

Boards for HiPath 3000
P31003-H3550-S403-4-7620, 02/05
3-338 HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
boards.fm
Options
Contact assignments
Table 3-162 GEE12, GEE16, GEE50 (Not for U.S.) - Contact Assignments
Contact Connector X3 Connector
X4
Connector
X5
1 a GND * CO 1 (AL1) 0V
2 b CO 1 (BN 1) CO 1 (BL1) 0V
3 a CO 1 (AN 1) CO 2 (AL2) RTS
4 b CO 2 (BN 2) CO 2 (BL2) CTS
5 a CO 2 (AN 2) CO 3 (AL3) RxD
6 b CO 3 (BN 3) CO 3 (BL3) TxD
7 a CO 3 (AN 3) CO 4 (AL4) 0V
8 b CO 4 (BN 4) CO 4 (BL4) +5V
9 a CO 4 (AN 4) – 0V
10 Call charging module as-
signment
–+5V
* for GEE 50 in France; otherwise free
