Siemens HiPath 3000 Service Manual

Boards for HiPath 3000
P31003-H3550-S403-4-7620, 02/05
3-358 HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
boards.fm
Options
STRB and STRBR board relay and sensor functions
Figure 3-162 STRB and STRBR Board Relay and Sensor Functions
STRB or STRBR
K1.21
K1.22
K1.23
K1.11
K1.12
K1.13
Relay
+12 VI+12 V
OPTKP1
To system
Short the wires to activate the
sensor.
Sensor
