inst_h3.fm
P31003-H3550-S403-4-7620, 02/05
HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
4-57
Installing HiPath 3000
Installing HiPath 3800
Information on cable and connector assignment is provided in the board descriptions in
Chapter 3.
Closing the backplane of the system cabinets
Slot with
SLMA
SLMO2
CABLUs for connection between backplane (SIVAPAC connector) and
MDFU-E (jumper strip for 25 TW):
● C39195-A7267-A372: 3 m in length, short stripped length for MDFU-E
slots 11-21 (see Figure 4-36)
● C39195-A7267-A373: 3 m in length, long stripped length for MDFU-E
slots 1-10 (see Figure 4-36)
CABLU for connection between backplane (SIVAPAC connectors) and ex-
ternal patch panel S30807-K6143-X (SIVAPAC socket terminal strip):
● S30267-Z333-A20: 2 m in length (refer to Figure 4-42)
● S30267-Z333-A50: 5 m in length (refer to Figure 4-42)
Open-end cable (24 TW) for connection between backplane (SIVAPAC con-
nector) and external patch panel:
● S30267-Z196-A150: 15 m in length
● S30267-Z196-A250: 25 m in length
● S30267-Z196-A350: 35 m in length
● S30267-Z196-A550: 55 m in length
● S30267-Z196-A950: 95 m in length
1For U.S. only
>
After the cable has been connected, the backplane of the basic cabinet and that of
the expansion cabinet (if applicable) must be closed with the dummy panels provid-
ed (C39165-A7075-C44).
If Then
