Siemens HiPath 3000 Service Manual

inst_h3.fm
P31003-H3550-S403-4-7620, 02/05
HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
4-69
Installing HiPath 3000
Installing HiPath 3800
Color Codes for the Open-End Cable
Table 4-8 Color Codes for the Open-End Cable
Color Group Pair a-Wire
(Tip)
b-Wire
(Ring)
Color Group Pair a-Wire
(Tip)
b-Wire
(Ring)
1 1 wht/blu 4 16 yel/blu
blu/wht blu/yel
2 wht/ora 17 yel/ora
ora/wht ora/yel
3 wht/grn 18 yel/grn
grn/wht grn/yel
4 wht/brn 19 yel/brn
brn/wht brn/yel
5 wht/gry 20 yel/gry
gry/wht gry/yel
2 6 red/blu 5 21 vio/blu
blu/red blu/vio
7 red/ora 22 vio/ora
ora/red ora/vio
8 red/grn 23 vio/grn
grn/red grn/vio
9 red/brn 24 vio/brn
brn/red brn/vio
10 red/gry Note: In the case of cables with 16 double
wires, the specifications for pairs 17 to 24 are
not relevant.
gry/red
311blk/blu
blu/blk
12 blk/ora
ora/blk
13 blk/grn
grn/blk
14 blk/brn
brn/blk
15 blk/gry
gry/blk
