inst_h3.fm
P31003-H3550-S403-4-7620, 02/05
HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
4-139
Installing HiPath 3000
Installing HiPath 3750, HiPath 3700
Connection cables between the “8-slot” basic and expansion cabinets
If installing a multi-cabinet system, you must also connect the cables between the BC and ECs.
X98 EC1
EC2
1 SU connector each (16 TW) to the patch panel
X29 - X89 All 1 SU connector each (8 TW) to the patch panel (not for S
2M
)
X99 EC1
EC2
1 SU connector each (8 TW) to the patch panel (not for S
2M
)
If Then
Two-cabinet
System
Connect BC to EC1 = 2 cables (S30267-Z178-A13)
(see Figure 4-78)
Three-cabi-
net
System
● Connect BC to EC1 = 2 cables (S30267-Z178-A13)
● Connect BC to EC2 = 2 cables (S30267-Z178-A13)
(see Figure 4-79)
Table 4-15 Jack Assignment on the “8-Slot” Backplane
Connec-
tor
Cabinet Function
To Next Page
