inst_h3.fm
P31003-H3550-S403-4-7620, 02/05
HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
4-145
Installing HiPath 3000
Installing HiPath 3750, HiPath 3700
Figure 4-81 Structure of the Patch Panel S30807-K6143-X
X10
X15
PFT1
X9
X12
X13
X14
F8
F1
F2 F7F3 F5
F6F4
1
1
1
1
1
1
X12, X14
X13, X15
18765432
18765432
aaaaaaaabbbbbbbb
X11
18 20 22 24 26 28 30 32
17 19 21 23 25 27 29 31
2 4 6 8 10 12 14 16
1 3 5 7 9 11 13 15
34 36 38 40 42 44 46 48
33 35 37 39 41 43 45 47
X5 X1
SIVAPAC edge connectors: port for CABLU connection to the backplane
Front panel with 3 x 16 MW8 jacks
Slots F1–F8 for
surge protector
Options for connecting the external line network:
● Connection via the MW8 jacks on the front of the patch panels. Using jumper wire,
bridges must be inserted between the terminal strips X12 and X14 and between X13
and X15. The contact between the connector X5 and the first eight MW8 jacks is only
set up when wire bridges are present.
● Direct connector jumpering on the X12/X13 connector. Bridges are not necessary in
this case.
X9, X10, X11 and PFT1 not
used in HiPath 3000.
18765432
