Installing HiPath 3750, HiPath 3700
Distribution of the PCM segments
There are 64 time-division multiplex channels available for each PCM segment. Blockages oc-
cur if these are busy. The system cannot execute any more call requests.
To guarantee that the system operates without blocking, make sure when you perform config-
uration that the boards on a PCM segment do not require more than the 64 time-division mul-
tiplex channels that are available. The following table lists the number of time-division multiplex
channels that the different boards require.
Table 4-16 Number of Time-Division Multiplex Channels Required Per Board
Board Number of time-division multiplex channels required
CR8N 8
HXGM3 (without extension
modules for additional DSP
channels)
16
IVML8 8
IVML24 24
SLA8N, SLA16N, and
SLA24N
Depends on the number of stations
SLC16/SLC16N Depends on the number of mobile telephones logged on
SLMO8, SLMO24 Depends on the number of stations (hosts (master) and clients
(slave))
STMD8 16
TIEL 4
TMDID8 8
TML8W 8
TMS2 30
TMST1 24
