Siemens HiPath 3000 Service Manual

inst_h3.fm
P31003-H3550-S403-4-7620, 02/05
HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
4-197
Installing HiPath 3000
Installing HiPath 3550, HiPath 3350, HiPath 3500, and HiPath 3300
Static traffic capacity
The HiPath 3500 and HiPath 3300 systems have the following static traffic capacities.
Table 4-23 HiPath 3500 and HiPath 3300 - Static Traffic Capacity
System Slots Static traffic capac-
ity
Total static traffic capacity
of the system
HiPath 3500
(see Figure 4-
111)
2/3 (CBRC) 24 erlangs
134 erlangs
4 16 erlangs
5 16 erlangs
6 16 erlangs
7 16 erlangs
8 16 erlangs
9 30 erlangs
1
1 Use of a TS2R board results in a capacity of 30 erlangs. A maximum of one TS2R per HiPath 3500 is possible, and the
board may only be installed in slot 7 or 9, thus resulting in 30 Erlangs for slot 7 or 9.
HiPath 3300
(see Figure 4-
112)
2/3 (CBRC) 24 erlangs
56 erlangs4 16 erlangs
5 16 erlangs
