boards.fm
P31003-H3550-S403-4-7620, 02/05
HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
3-3
Boards for HiPath 3000
Overview
Peripheral boards
Note: The HiPath 3550, HiPath 3350, HiPath 3500 and HiPath 3300 peripheral boards must
be firmly inserted into their slots; otherwise contact problems can cause board failure.
DIU2U S30810-Q2216-X HiPath 3800 (for U.S. only)
DIUN2 S30810-Q2196-X HiPath 3800
HXGM3 S30810-Q2942-X HiPath 3750/HiPath 3700
HXGR3 S30810-K2943-Z HiPath 3500/HiPath 3300
HXGS3 S30810-Q2943-X HiPath 3550/HiPath 3350
IVML8 S30122-X7380-X100 HiPath 3750/HiPath 3700
IVML24 S30122-X7380-X HiPath 3750/HiPath 3700
IVMN8 S30122-H7688-X100 HiPath 3800
IVMNL S30122-H7688-X HiPath 3800
IVMP8 S30122-Q7379-X100 HiPath 3350 (not for U.S.)
IVMP8R S30122-K7379-Z100 HiPath 3300 (not for U.S.)
IVMS8 S30122-Q7379-X HiPath 3550/HiPath 3350
IVMS8R S30122-K7379-Z HiPath 3500/HiPath 3300
PBXXX S30810-Q6401-X HiPath 3800
SLA8N S30810-Q2929-X200 HiPath 3750/HiPath 3550/HiPath 3700
(not for U.S.)
SLA16N S30810-Q2929-X100 HiPath 3750/HiPath 3550/HiPath 3700
SLA24N S30810-Q2929-X HiPath 3750/HiPath 3550/HiPath 3700
SLC16 S30810-Q2922-X HiPath 3750/HiPath 3550/HiPath 3700
(not for U.S.)
SLC16N S30810-Q2193-X100 HiPath 3750/HiPath 3550/HiPath 3700
(not for U.S.)
SLCN S30810-Q2193-X300 HiPath 3800 (not for U.S.)
SLMA S30810-Q2191-C300 HiPath 3800
SLMA8 S30810-Q2191-C100 HiPath 3800
SLMO2 S30810-Q2168-X10 HiPath 3800
SLMO8 S30810-Q2168-X100 HiPath 3800
SLMO8 S30810-Q2901-X100 HiPath 3750/HiPath 3700 (not for U.S.)
SLMO24 S30810-Q2901-X HiPath 3750/HiPath 3550/HiPath 3700
Table 3-1 HiPath 3000 - Functional Overview of All Boards Used
Board Part number Model
