HiPath 5000 Startup and Administration
P31003-H3550-S403-4-7620, 02/05
6-52 HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
start_h5.fm
Perform HiPath 5000 Basic Configuration
● load from system
To load a CDB directly from a node.
If the Copy netwide data in node option is activated, the service and substitution codes
are copied from the CDB firstly created to all other CDB files of the node belonging to IP
networking.
4. Confirm the selection of the source with the Finish button.
5. To add the node, invoke File - HiPath 5000/AllServe - Transfer - HiPath 5000/AllServe
Server.
6. The Transfer (HiPath 5000/AllServe Server) dialog appears.
Apply the node data to the server net file by clicking the Add node button.
7. Finally, rewrite the data from HiPath 3000 Manager E to the HiPath 5000 server (Manager
–> Server button).
>
Refer to the Help for HiPath 3000 Manager E for additional information about the
procedure.
