Workpoint Clients
P31003-H3550-S403-4-7620, 02/05
10-4 HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
wclient.fm
optiPoint 500
Key programming
You can label the keys in one of the following ways:
● by hand (in writing); label sheets come with each telephone.
● using a PC:
– with the "Key Labeling Tool" (requires MS Word
©
) that is on the CD "Electronic Oper-
ating Instructions" (refer to Section 1.6, “Information on the Intranet”: Electronic Docu-
mentation on Com ESY Products).
– with the “Online Key Labeling Tool” that can be downloaded from http://www.sie-
mens.com/hipath (–> Downloads).
>
Double key assignment
The programmable function keys of the optiPoint 500 telephones and the optiPoint
key modules can have double assignments if only call numbers without LED support
are saved on the first level. It is also possible to program call numbers without LED
support on the second level. These can be internal station numbers, DID call num-
bers and call numbers from a HiPath network.
When the Shift function is pressed, the LED associated with the Shift key lights up.
This signals that the phone numbers on the second key level are available. The Shift
function is deactivated after 5 s or after you press a phone number or if you press
the Shift key again.
The optiPoint BLF function keys cannot have double assignments.
