Workpoint Clients
optiPoint 500
4 "Call" con-
tact
Signals the call receipt state.
This can be used, for example, to control a secondary bell.
The contact can be loaded with up to 5 W at 24 Vac or 60 Vdc.
5
6Free –
Table 10-1 Floating contacts on the optiPoint acoustic adapter
Pin Assign-
ment
Notes
