wclient.fm
P31003-H3550-S403-4-7620, 02/05
HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
10-81
Workpoint Clients
IP Telephony (Voice over IP)
Branch performance requirements
Four gateway channels via LAN interface 2 with AES encryption should be included in the cal-
culation. As described in Table 10-9, eight gateway channels are required for 30 IP workpoint
clients (at 0.1 erlangs/workpoint client). Since VPN functionality is required, the WBM setting
"Enhanced B Channels" is deactivated.
The determined resource requirement of 696.1 points is less than the overall performance of
780 points which the HXGR3 board can provide. The branch configuration is feasible.
Function Resource require-
ment
(credit point)
Signaling without
H.235 security (inde-
pendent of the WBM
setting "Enhanced B
Channels")
30 x IP workpoint client: System Client, HFA
client, H.323 client (eight calls an hour)
30 x 0,51 = 15.3
4 x IP networking channel (25 calls per hour) 4 x 3.2 = 12.8
Payload (additional
feature: Enhanced B
Channels Disabled
over WBM.)
Voice gateway channel over LAN interface 2 with encryption:
4 x G.711 (received: 20 msec/sent: 20 msec)
with AES encryption
4 x 89.0 = 356.0
Voice gateway channel over LAN interface 1 without encryption:
8 x G.711 (received: 20 msec/sent: 20 msec) 8 x 39.0 = 312.0
Total = 696.1
