wclient.fm
P31003-H3550-S403-4-7620, 02/05
HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
10-85
Workpoint Clients
IP Telephony (Voice over IP)
Each IP networking connection requires 92.2 performance points.
Up to four simultaneous connections are possible with the 385 performance points available for
networking connections (385 / 92.2 = 4.18).
Bandwidth requirement
For information on bandwidths, refer to the System Description HiPath 3000/5000 V5.0.
A 2 Mbps connection would be sufficient for this configuration.
Payload (additional
feature: Enhanced B
Channels Disabled
over WBM.)
Voice gateway channel over LAN interface 2 with encryption:
G.729 (received: 20 msec/sent: 20 msec)
with AES encryption
89.0
Total = 92.2
Bandwidth calculation Bandwidth Totals
4 channels with AES encryption,
G.729 with a sample rate of 20 msec
4 x 60 Kbps 240 Kbps
Data transfer 1024 Kbps
Total = 1264 Kbps
Function Resource require-
ment
(credit point)
